Door screens

Door insec screen - Type H1

Door screens against insects protect against all types of insects. Door screen H1 is practical and necessary protection against insects in rooms with entrances onto terraces or balconies. Door screen H1 is designed for balcony doors and windows with large dimensions. The advantage of this anti-insect door screen is the principle of self closing.

The frame colour can be selected in wood imitation, Renolite or any RAL colour. Due to the extensive colour range, the screen can be matched with any plastic or wooden window.

I am interested in this product

Advantages

Benefits & advantages

cylindrical aluminium frame
higher frame rigidity
self-closing frames
easily removable from the balcony door
the colour of the frame is according to the RAL sampler, in wood imitation or coated in Renolite

Get

Inspiration

Explore

Colour variants

Basic colours frame

Renolit colours at extra charge frame

Colour performance Isotra System Decoral 1 at extra charge frame

other colours

Colour performance Isotra System Decoral 2 at extra charge frame

Hereby stated colors are only indicative. If you want to see the color in real we recommend to visit one of our business partners where you can ask for physical swatch. We cannot accept claims for inappropriately chosen color according to electronic sampler.

Guaranteed

Dimensions

minimum width
600 mm

maximum width
1500 mm

minimum height
1400 mm

maximum height
2400 mm

maximum area
3 m²

non-standard dimensions are not produced.

Technical parameters

	Frame	Method of fixation	Number of assembly clamps	Corner		Screen
	Frame	Method of fixation	Number of assembly clamps	internal	external	grey	black	reinforced	white*
Business name	SC 202 / 1	fastener	3	Yes	Yes	Yes	Yes	Yes	Yes
Dimensions (mm)	51 × 20
Material	Al
Cross-section
Colour	Standard: RAL 9003 white RAL 8019 brown RAL 7016 anthracite gray Surcharge: other RAL colours sprayed (double sided) Renolite according to the sampler (single sided) ISOTRA System Decoral I, II

* It is valid for the white mesh that one of the measures (width or height) have to be smaller than 1 450 mm.

Assembly options

on the frame of the balcony door
on the frame with bigger dimensions

Download

Control and maintenance manual

Leaflet Insect screens

Leaflet Sun protection systems

Measurement and assembly manual H

Order form

Technical manual
